Stock no. E-4711 81 gallon/307 liter 316L Stainless Steel Portable Jacketed Tank MFG Inox Industries of Toronto, p/n N07-062-02, year 2007 Rated for FV/15 psi , side jacketed with 2 fittings 30 inch diameter x 22 inch with dished bottom and clamped top with seal 18 inch center clamped lid with (4) 1.5 inch and […]
Stock no. E-4706 45 gallon Stainless Steel Jacketed Tank w/Sweep Agitator Labeled for Fragrances & Flavors 24 inch inside diameter x 25 inch deep with concave slant bottom Tri-clamp 2 inch side outlet at lowest point with another 3 inch slightly higher Also a 2.5 inch side inlet and (3) 2 inch top inlets Has […]
Stock no. E-4702 160 gallon Sanitary Stainless Steel Closed Top Cone Bottom Jacketed Tank Creamery Package CREPACO serial no. C1841 40 inch diameter x 24 inch straight side w/12 inch bottom cone, closed top Tri-clamp 3 inch bottom center outlet >2 inch 3 inch and (2) 1.5 inch top inlets, 2 inch top vent, bottom […]
Stock no. E-4674 (4) 94 gallon/350 liter Stainless Steel Portable Jacketed Pressure Tank with agitator MFG All-Weld of Ontario, Canada, no. SDR-1030 No pressure rating listed, but similar to others rated for 15 psi 32 inch diameter x 27 inch with dished bottom and clamped top with seal Has side jacket with (4) side inlet […]
Stock no. E-4652 200 liter/53 gal STAINLESS STEEL DIMPLE JACKETED TANK Stainless Fabrication Inc. serial no. 18107-1-1, model VE069300 Could not see a mfg’s plate, info provided by previous owner 29.5 inch inside x 19.5 inch deep with flat bottom and open top (57 gal total) On 4 legs with wheels, external handles, o/a 40 […]
Stock no. E-4650 100 gallon STAINLESS STEEL DIMPLE JACKETED TANK 50 PSI Perma San model 100 gallon JOVS, serial no. 33812-2 Single zone side and bottom dimple jacket rated for 50 psi @ 300 deg. F 30 inch id x 33 > 34.5 inch slant bottom and open top (4) legs, 62.5 inch to top […]
Stock no. E-4631 2080 liter/549 gal SANITARY STAINLESS STEEL JACKETED TANK Manufactured in 2014 by Blue Current Brewery of China Type SF2000, 2080 liter capacity. No pressure plate, assume low pressure jacket. Half-side dimple jacket with 3/4 inch fittings 43 inch inside diameter x 74 inch straight side with concave bottom, open top On 4 […]
Stock no. E-4625 220 gallon 304 SS DIMPLE JACKETED SANITARY TANK Certified by A & B Process Systems, serial no. 30968301, year 2003 National board no. 315, U and W stamped. Single zone jacket Side and bottom dimple jacket rated for 180 psi @ 300 deg. F to -20 deg. F 36 inch diameter x […]
Stock no. E-4602 (5) 150 gallon STAINLESS STEEL JACKETED TANK SLANT BOTTOM 36 inch x 36 inch with slant bottom, open top, Has bracket for mixer Side is insulated and side jacketed Also has electric tube type heaters for the bottom (unsure if in working order) Has 1.5 inch side outlet. Last used for candle […]
Stock no. E-4533 55 gallon STAINLESS STEEL JACKETED TANK 22.5 inch inside diameter x 34 inch with a side jacket 2.25 inch bottom center outlet To be cleaned and jacket pressure tested (1) available
Stock no. E-4504 3 gallon STAINLESS STEEL JACKETED TANK with MIXER 8.75 inch inside diameter x 12 inch deep, flat bottom, clamped top (2) motor option, both 1/8 Hp, 90 v dc with speed controls Motors have different size pulleys for additional speed options (6) 1/4 inch top inlets with (3) dip tubes. 1/4 inch […]
Stock no. E-4320 (4) 6 gallon ELECTRIC KETTLE JACKETED TANK SWEEP AGITATOR 12.5 inch inside diameter x 11 inch with dish bottom, 2 piece lid Polished stainless steel. Has a label SSS 40 Watt half sweep agitator, 90 Watt for center shaft to bottom metering out 200-240 V., 3 ph gear reduced induction motors on […]
Stock no. E-4306 30 gallon STAINLESS STEEL REACTOR JACKETED TANK 16 inch diameter x 36 inch w/dished bottom clamped dished top, 21 inch outside diameter has plate with these numbers only 6701-18 4-4100-127 jacketed and insulated, no rating listed tri-clamp top = 4 inch, 2 inch, (2) 2.5 inch, and (4) 1 inch. Approx. 2 […]
Stock no. E-4305 200 gallon MUELLER TANK with INTERNAL PLATE COIL Model RHP200, no. 105738 .23 cu. ft. coil volume, 113 psi max, originally R-12 medium 46 inch inside diameter x 33 > 34.5 inch slant bottom 1.5 inch tri-clamp side outlet on low side, 1.5 inch threaded side outlet opposite side 31 inch diameter […]
Stock no. E-4233 (2) 100 gallon STAINLESS STEEL JACKETED TANK 24 inch diameter x 48 inch with cone bottom, open top 1 inch bottom center outlet and side outlet, 2 inch side inlet 3/4 inch thermal well. 1/2 side jacket with 1 inch jacket inlet and outlet Has gussets that we can add legs to. […]
Stock no. E-4174 350 gallon 304 STAINLESS STEEL JACKETED TANK 41.5 inch inside diameter x 60 inch with dished bottom, open top Has 2 sets of brackets for baffles, approx. 2 inch bottom center outlet Side probe inlet and 1 inch side outlet Has carbon steel jacket, side and bottom inlets and outlets (1) available
Stock no. E-4021 (3) 125 gallon STAINLESS STEEL TANK WITH EXTERNAL COILS 125 gallon stainless steel cone bottom tank with external coil wrap 30 inch diameter x 36 inch straight side with 6 inch cone bottom, flat top 3 inch bottom center outlet, 1 inch diameter coils, hinged lid (not shown) Coils are not part […]
Stock Number: E-3886 0.65 GALLON STAINLESS STEEL JACKETED PRESSURE TANK Mfg. Acme Industrial Shell = FV/110 psi, jkt. = 80 psi @ 325 deg. F Marked 1.7 liter, total capacity = .65 gallon 4.75 inch id x 8.5 inch deep, flat bottom Clamped flat top with dip tube No bottom outlet (1) available
Stock Number: E-3885 1.2 GALLON STAINLESS STEEL JACKETED PRESSURE TANK Mfg. Acme Industrial Shell= FV/110 psi, jkt.= 80 psi @ 325 deg. F Marked 4 liter capacity, Total volume = 1.20 gallon 4.75 inch id x 15.75 inch, flat bottom, no outlet Has clamped flat top with dip tube (1) available
