145 sq. ft. PLATE and FRAME HEAT EXCHANGER TITANIUM PLATES

Stock no. G-3849 145 sq. ft. PLATE and FRAME HEAT EXCHANGER TITANIUM PLATES APV model no. LR2 MGS-27,  year 2004. serial no. scratched Rated for 200 psi, 23 to 239 deg. F temp. range Square footage is estimated. Need to confirm no. of plates. Labeled 48 plates, 0.5 mm. Titanium plates originally per mfg (4) […]

520 sq. ft. PLATE and FRAME HEAT EXCHANGER SS PLATES

Stock no. G-3834 520 sq. ft. PLATE and FRAME HEAT EXCHANGER SS PLATES Alfa Laval model no. 7786745,  yr 2013, serial no. 30115-72-81 Rated to 150 psi @ 220 deg. F, MDMT -20 @ 150 psi A dim 240 mm with (80) .5 mm plates Stainless steel plates 8-bolt fittings with adapters (2) 2 inch […]

129 sq. ft. PLATE and FRAME HEAT EXCHANGER TITANIUM PLATES

Stock no. G-3831 129 sq. ft. PLATE and FRAME HEAT EXCHANGER TITANIUM PLATES Alfa Laval model no. M10BWFDR yr 1996, s/n 30102-87971 Rated for 150/250 psi @ 176 deg. F, MDMT -5 deg. F. 50 plates. A dimensions 154 mm Per mfg. originally supplied with Titanium plates (2) 4 inch welded tubes to frame and […]

70 sq. ft. PLATE and FRAME HEAT EXCHANGER TITANIUM PLATES

Stock no. G-3829 70 sq. ft. PLATE and FRAME HEAT EXCHANGER TITANIUM PLATES KDS Inc. model no. M10MFM-29, serial no. KDS1915 Rated for 70 sq. ft., 100 psi @ 320 deg. F. (28) plates. (4) 3.5 inch 8-bolt fittings o/a 19 x 43 x 31 inch tall (1)  available

2730 Btu R025 HASKRIS WATER COOLED CHILLER 115 V

Stock no. G-3897 2730 Btu per Hour HASKRIS WATER COOLED CHILLER Model R025, serial number HB20622 R134A refrigerant, 2 lbs. 10 oz charge 4.9 RLA, 25 LRA, 1 Ph compressor 1/3 Hp pump, 5.6 FLA, 115 v, 1 ph Digital controls, water level gauge Return and supply in and out, water in and out fittings […]

22.76 sq. ft. STAINLESS STEEL SHELL and TUBE HEAT EXCHANGER

Stock no. G-3881 22.76 sq. ft. STAINLESS STEEL SHELL and TUBE HEAT EXCHANGER 316 or 316L Stainless. No plate.  Serial number on head is 4150930-9 Originally on a Mueller Pyro Pure model P7505 steam generator Rating confirmed by Mueller, rated for 150 psig and FV at 366 deg F. 5.5 inch diameter  x 30.5 inch […]

500 Kw STAINLESS STEEL SHELL AND TUBE CHROMALOX HEATER

Stock no. G-3882 500 Kw STAINLESS STEEL SHELL AND TUBE CHROMALOX HEATER Catalog no. NWHSS-108500PE1X, part no. 054-551511-096-239DP U stamped, National Board 21528, rated for 30 psi @ 250 deg. F, -20 F @ 30 psi Serial number 06937, year 2008. 304 stainless steel  shell & tubes 18 inch diameter insulated shell x 126 inch […]

9.75 cu. ft. BLUE M ENVIRONMENTAL CHAMBER 200 F 98% HUMIDITY

Stock no. G-3877 (2) 9.75 cu. ft. BLUE M ENVIRONMENTAL CHAMBER 200 F 98% HUMIDITY Model CFR7752C, serial no. C2-603 Stainless steel contacts, double door with inner plexi-glass door 36 inch w x 18 inch deep x 26 inch tall inside. O/a 51 inch x 40 inch x 80 inch tall 38>200 deg. F, 40>98% […]

12 Kw CONAIR HOT WATER HEATER CONTROLLER CIRCULATOR 480 V

Stock no. G-3865 12 Kw CONAIR HOT WATER HEATER TEMPERATURE CONTROLLER Model MSMB4B10, serial no. 4M0042, date 2/84 12 Kw, 1 Hp, 480 volt, 3 ph, 16.9 A max 1/2 inch water in and out, 1 inch x 1.25 inch process in and out Measures 16 x 36 inch with fittings on back x 22 […]

27 cu. ft. BLUE M ENVIRONMENTAL CHAMBER 200 deg. F

Stock no. G-3818 27 cu. ft. BLUE M ENVIRONMENTAL CHAMBER BLUE M ELECTRIC  serial no. F1-411, model no. FR361C-1 Stainless steel internals measuring 3 ft. x 3 ft x 3 ft Over all 52 inch X 80 inch X 7 ft. tall Temperature range -18 deg C , 93 deg C (200 deg. F) (2) […]

3.7 cu. ft. 200 F ENVIRONMENTAL CHAMBER

Stock no. G-3837 3.7 cu. ft. 200 F ENVIRONMENTAL CHAMBER TENNEY ENGINEERING model THJR. serial no. SB11469-85H-529 inside dimensions = 20 x 20 x 16 inch, o/a  22 x 45 x  30 inch tall temp range 10 to 200 deg. F with humidity control stainless steel contacts (1) 2 inch side vent, approx. 1 inch […]

95 deg C ENVIRONMENTAL CHAMBER HUMIDITY CHAMBER

Stock no. G-3743 95 deg C ENVIRONMENTAL CHAMBER HUMIDITY CHAMBER Hotpack model 435300, s/n 65105 Inside  27″h x 30.5″ w x 21.5″ d, o/a 48″ x 28″ x 39″ H Stainless steel interior, rated to 95 deg. C. temp + humidity space for (10) 21″ x 30″ shelves(not included) has plexiglass inner door. 115V, 50/60 […]

99 sq. ft. PLATE and FRAME HEAT EXCHANGER TRANTER

Stock no. G-3671 99 sq. ft. PLATE and FRAME HEAT EXCHANGER TRANTER SuperChanger Model UX-125-UJ-48, drawing D-4-89719 Serial no. SA935, National Board no. 35491, year 200_ (plate needs cleaning) Rated for 99 sq. ft., 150 psi @ 350 deg. F. Stainless steel plates, 4.91″ min. 5.29″ max plate pack. (4) 2″ threaded in/out with reducers […]

18 Kw-480 v HOT OIL HEATER CHROMALOX

Stock no. G-3635(2) 18 kw-480 v HOT OIL HEATER Manufacturer Chromalox Model COHT 18 P, p/n 141-12289-012, s/n pc 00818 O/a 15″ x 45″ x 62″ tall Push button set controls with +50/-50 deg. F alarm, gauge to 700 F. 3/4″ pipe in and out. On wheels Electrical data 480 v, with 120 v controls (2) Similar […]

10 ton MOKON LIQUID CHILLER ICE MAN SC

Stock no. G-3661 10 ton MOKON LIQUID CHILLER Model WS4A10JY, # 68050, Ice Man SC Dimensions o/a 37″ x 48 l x 45″ h Inlets/outlets 1.5″ process i/o, 1.5″ H2O drain, 1.5″ supply, .5″ fill Has manual, digital control, R-22 10 hp, 460 V, 3 ph, 17.5 amp Does need some work/recharge, plugged it in and […]

3240 btu/hr HASKRIS AIR COOLED CHILLER

Stock no. G-3633 3,240 btu/hr HASKRIS AIR COOLED CHILLER Haskris serial no. H-A11327. Model RO 033 Rated for 950 watts, 3,240 btu/hr (2) 1/2″ in/out supply/return 1/3 hp pump, 1725 rpm, 1 gpm 5 gallon reservoir cap, R 134a refrigerant 115 V, single phase, 60 hz, 13.5 amps Here is a link to the manufacturer’s web […]

11 sq ft HELIFLOW HEAT EXCHANGER CARBON STEEL

11 sq ft HELIFLOW HEAT EXCHANGER CARBON STEEL Stock no. G-3426 Manufacturer Graham Corporation. Serial no. 99-41153-01,15-ss-16L, item h-9011 National Board no. 28287 Rating= shell+tube Full Vacuum/100 psig @ 350 deg. F, -20 deg. F min (3) 2″  inlets/outlets, 3″ outlet (1) available

4 Kw HOT WATER HEATER 480 volt

Stock no. G-3530 4 Kw HOT WATER HEATER 480 volt Ogden 4 Kw hot water heater, circulating type Catalog no.  K8A-18-0030-M2 480 v, 3 ph 2.5″ side inlet and outlet, 1″ drain (1) available

235 sq. ft. APV STAINLESS STEEL PLATE HEAT EXCHANGER

Stock no. G-3531 235 sq. ft. APV STAINLESS STEEL PLATE HEAT EXCHANGER APV model R66 , no. 16420-1 (41) 28 inch x 58 inch stainless steel plates (4) 8 inch inlets and outlets O/a 36 x 51 x 77 inch tall (1) available

12 KW STERLCO HOT OIL HEATER 460 volt

Stock no. G-3484 Sterlco/Sterling Inc. 12 Kw  hot oil heater Model F6016 DX single zone heating, no. 45378, B682-05223 Gauge 100 to 550 deg. F 3/4 Hp pump, series 400 controller (4) 1″ inlets & outlets 460 volt, 3 ph with 115 v, 1 ph controls (1) available

40 KW 575V CHROMALOX HOT WATER HEATER

Stock no. G-3379 (2) 40 KW 575V CHROMALOX HOT WATER HEATER Chromalox model cwg 250 40vcaxx, p/n 141 122 980 018 210 psi @ 300 deg F max, rated for 250 deg F (3) 1.5″ i/o, .5″ outlet, 1″ inlet 575 volt, kw 40, 3 ph, 60 hz, 120v control 1.15 hp pump (2 )available

8 CU. FT. MECHANICAL TEST REFRIGERATOR ENVIRONMENTAL CHAMBER

Stock no. G-3448 8 cu. ft. ENVIRONMENTAL CHAMBER TEST REFRIGERATOR Bemco Serial no. 3686-4, model F-45/200-8, 3/88 24 inch cubed interior, o/a 37 x 49 x 73 inch tall on wheels Stainless steel interior Wide range mechanical test refrigerator, -100 to 350 F Inlets/outlets (2) 2.75 inch vents, in/out bottom fittings Top mounted blower/fan Separate […]

119,000 BTU AFFINITY HEAT EXCHANGER RECIRCULATOR

Stock Number: G-3442 119,000 BTU AFFINITY HEAT EXCHANGER RECIRCULATOR Circulating pump with heat exchanger Model EWA 08BCDD 9CA Rated for 119,000 Btu/Hr 208-230 volt, 1 ph circulating pump (4) 1 inch inlets and outlets (1) available

1 .67 MIL BTU/HR CLEAVER BROOKS OIL FIRED BOILER

Stock Number: G-1841 1 .67 MIL BTU/HR CLEAVER BROOKS OIL FIRED BOILER Mfg. Cleaver Brooks Package Boiler Model P100-40, no. 66638 Rated for 15 psi, 1,674,000 Btu per Hr input 1,350,000 Btu per Hr output. Oil fired, 12 GPH Skid mounted 50 inch x 136 inch long x 5 ft. tall Selling AS IS. (1) […]

3 SQ. FT. SPIRAL HEAT EXCHANGER

Stock Number: G-1871 Mfg. American Heat Reclaming Corp. Type 1-H, no. 15214, 1982, NB 11881 shell = 304 stainless steel, hd = SA515-70 rated for 75 psi @ 200 F (4)3 inch in and out, (2)1 inch drains (1) available

3.5 sq ft 316 STAINLESS STEEL U-TUBE HEAT EXCHANGER

Stock Number: G-2539 3.5 sq ft 316 STAINLESS STEEL U-TUBE HEAT EXCHANGER Mfg. Alleghany Bradford Corp. Serial no. 8177-03, UM stamped 316 stainless steel Shell and tubes rated for 150 psi @ 350 F 6 inch diameter x 6 ft., (12) 5/16 inch od tubes, 2 pass design 3/4 inch tri-clamp in and out on […]

4 SQ. FT. GLASS LINED CONDENSER

Stock Number: G-2917 Mfg. Pfaudler no. 80-97-066, 1997. 9115 glass Rated for 150 psi @ 450 F Single 3 inch inside diameter tube 3 inch in and out, Jacketed 1,5 inch in and out 14 x 14 x 84 inches overall (1) available

4 SQ. FT. SCRAPE SURFACE HEAT EXCHANGER

Stock Number: G-1472 4 SQ. FT. SCRAPE SURFACE HEAT EXCHANGER Mfg. Contherm DeLaval Model 6×4, Nickel construction Has hydraulic drive that may need work Selling as is. (1) available

4.25 TON RECIRCULATING HEAT EXCHANGER

Stock Number: G-2620 Mfg. Lepel Type 18310017, model RWWEX-10, s/n 8457 1.5 Hp, 208 volt, 1 ph, 4.5 a, 15Kw, 51,225 Btu/Hr Gauge to 140 F/60 C, 100 psi 15.5 in. x 8 in. x 18 in. reservoir, 10 gallon Brass 1 in. water in and out, 1.5 in. process in and out (1) available

7 .47 SQ. FT. SHELL AND TUBE HEAT EXCHANGER

Stock Number: G-3127 Mfg. Young Radiator Co. Model F 302-HY 4P converted to single pass Shell and tube rated for 150 psi @ 350 deg. F 1 inch and 1.5 inch inlets and outlets Bronze, copper, & iron construction (1) available

9 KW STERLCO HOT WATER HEATER CIRCULATOR 460 v

Stock Number: G-3319 9 KW STERLCO HOT WATER HEATER CIRCULATOR Sterling model SX9412-CX hot water temp. controller Rated for 9 KW to 250 deg. F 3/4 Hp Circulating pump, 20 gpm @ 20 psi 460 v, 3ph, 13a, with 115v Digital Controls Has (4) rear inlets and outlets (1) available SALE PENDING

20 KW CHROMALOX HOT OIL HEATER 550 volt

Stock Number: G-3081 20 KW CHROMALOX HOT OIL HEATER 550 volt Mfg. Chromalox Model TMO-620B, no. BG23291 550 volt, 3ph, with 110v controls 2 Hp, 1735 rpm pump motor 2 inch in and out Upgraded digital controls (1) available

23 CU. FT. PUFFER HUBBARD LAB REFRIGERATOR

Stock Number: G-3240 Mfg. Puffer Hubbard Model LR-23-1G 21 x 27 x 50 inch id, approx. 3 x 4 x 6 ft. over all Takes R12 refrigerant, 33 to 46 deg F Chart recorder, battery powered alarm 115v, 1ph, 9.62 amp total load (1) available

27 CU. FT. VACUUM OVEN T M VACUUM PRODUCTS

Stock Number: G-3368 27 CU. FT. VACUUM OVEN T M VACUUM PRODUCTS Mfg. T-M Vacuum Products Model PC 36-6 with updated digital controls Rated to 200 deg C, 460v, 100 amps Stainless steel internals 38 x 33.75 x 36.25 inch Brackets, but no shelves. Has refrigerated cold trap 1/2 Hp fan (1) available

30 CU. FT. GAS FIRED OVEN

Stock Number: G-1595 30 CU. FT. GAS FIRED OVEN Mfg. Proctor & Schwartz Number K17605 31 x 40 x 44 inch tall inside dimensions Gas fired heat, 5 Hp 208 v, 3ph blower, adjustable  speed (1) available

60 DEG. C INCUBATOR OVEN

Stock Number: G-3264 Mfg. Precision Scientific Model 31485, rated for 600 watts, 60 deg. C 120 volt, 5.2 amp Interior is 18 x 36 x 27 inches Has one shelf and interior glass doors (1) available

76 sq. ft. STAINLESS STEEL PLATE HEAT EXCHANGER

Stock Number: G-3243 76 sq. ft. STAINLESS STEEL PLATE HEAT EXCHANGER Mfg. APV Heat Transfer, serial no. 75371, w.o. 13265-2, year 1981 Model R56 rated for 125 psi @ 250 deg. F. National Board no. 620 ASME Paraflow Plate Heat Exchanger (16) Stainless steel plates 16.5 x 60 inch (4)4 inch in and out Square […]

90 GPH MUELLER PYRO PURE MULTI EFFECT STILL HEAT EXCHANGER

Stock Number: G-3387 90 GPH MUELLER PYRO PURE MULTI EFFECT STILL Mfg. Paul Mueller Co. Pyro Pure Model MES-75-3, serial no. 2044996-1 Rated to 90 gph/ 340 lph Approx. 331 lbs/hr, 150 kg/hr steam consumption National board stamped. A/B slc 5/03 plc 230v, 3ph Was part of a WFI system. Heat exchangers dated 1997 WILL CONSIDER […]

93 DEG. C BLUE M ENVIRONMENTAL CHAMBER

Stock Number: G-2110 93 DEG. C BLUE M ENVIRONMENTAL CHAMBER Mfg. Blue M Electric Model CF-7502HA, rated to 93 deg. C 1/4 Hp blower, 120 volt 19 x 13 x 20 inch tall id, o/a 35 x 25 x 44 inch tall Stainless steel contacts Internal glass door, water flow control (1) available

108 SQ. FT. APV PLATE HEAT EXCHANGER

Stock Number: G-1580 108 SQ. FT. APV PLATE HEAT EXCHANGER Mfg. APV Heat Transfer Technologies Model R66, s/n 15072 (20) 28 in. x 58 in. stainless steel plates (4)8 inch inlets and outlets (1) available

150 GPH MUELLER PYRO PURE STILL HEAT EXCHANGER

Stock Number: G-3288 150 GPH MUELLER PYRO PURE STILL FOR WFI Mfg. Mueller Co. Pyro Pure model MES P6015-3, multi-effect still Built in 2000. Used for WFI water for injection Condensor/controls/evaporator/preheater/steam separator Fristham 3 Hp, 3450 rpm, 2 x 1.5 pump 316/316L stainless steel contacts. Some pieces missing. WILL CONSIDER STRIPPING AND SELLING OFF HEAT […]

4.8 cu. ft. 200 DEG. F ENVIRONMENTAL CHAMBER

Stock Number: G-1571 4.8 cu. ft. 200 DEG. F ENVIRONMENTAL CHAMBER Mfg. Tenney Engineering Model 3TH-0200 -10 to 200 deg. F, R 12 Temp and humidity control Inside = 20 inch wide x 22 inch deep x 19 inch tall (1) available

9 sq. ft. MOKON LIQUID RECIRCULATOR HEAT EXCHANGER

Stock Number: G-3215 9 sq. ft. MOKON LIQUID RECIRCULATOR HEAT EXCHANGER Mfg. Mokon Model MT250024 1/3 Hp pump for circulating. 230 v, 3ph (4) .75 inch in & out, (2)1 inch in & out Rated to 250 deg. F.  9 sq. ft. Heat Exchanger, 2.5 gallon ss tank This model does not come with any […]

429 SQ. FT. STAINLESS STEEL PLATE HEAT EXCHANGER

Stock Number: G-3286 429 SQ. FT. STAINLESS STEEL PLATE HEAT EXCHANGER Mfg. Alfa Laval Rated for 75 psi @ 230 deg. F Model M 10 MFM, National Board stamped 181 stainless steel plates with 50 inch of free space. (4) 4 inch in and out 428.97 sq. ft. (1) available

617 DEG. F PRECISION SCIENTIFIC OVEN

Stock Number: G-2309 617 DEG. F PRECISION SCIENTIFIC OVEN Mfg. Precision Scientific Model 124A, cat. no. 3126Z 25 x 19 x 19 inch tall inside dimensions Rated to 325 deg. C/ 617 deg. F. 120/240 volts, single phase, 2800 watts (1) available

650 DEG. F. DESPATCH OVEN

Stock Number: G-3290 650 DEG. F. DESPATCH OVEN Mfg. Despatch Oven Co. LAD1-42-3, rated to 650 deg. F 240v, 1ph, 3 Kw, 15.6 amp. 1.4 Hp, 2.8 amp blower motor Interior 18 3/8 inch wide x 18 5/8 inch deep x 19 7/8 inch tall. approx. 8 x 8 inch top port O/a 33 inch […]

752 DEG. F LAB VACUUM FURNACE CATHODE HEAT TREATMENT

Stock Number: G-1062 752 DEG. F LAB VACUUM FURNACE CATHODE HEAT TREATMENT Mfg. Takemoto Ef Mfg. Co. No. 80032, Cathode Heat Treatment Furnace Temp to 400 deg. C/ 752 deg. F (3) heaters Id = 5 inch x 6.25 inch x 16 inch deep (1) available

1100 DEG. C TUBE FURNACE LINDBERGH

Stock Number: G-1238 1,100 DEG. C TUBE FURNACE LINDBERGH Mfg. Lindbergh Model 55773 5.25 inch inside diameter x 7 ft. long 11,000 watts, 240v, 45.8 amps, 60/50 hz Controls to 1100 deg. c (1) available

3300 BTU/HR AIR COOLED CHILLER

Stock Number: G-2289 3,300 BTU/HR AIR COOLED CHILLER Mfg. Alpha Environmental Refrigeration Model PCABDQ-1.5-XP-115, s/n 90422 1.5 Hp compressor, 1/2 Hp pump, R12 refrigerant 115v, 1ph, 60hz, xp 17.5 gallon poly reservoir, 1/2 inch cooper tubing Rated for 3 gpm, 55% Glycol, -17 to -20 deg. F (1) available

12 cu. ft. Lab Freezer

Stock Number: G-3035 Mfg. Forma Scientific Model 8400 Bio Freezer 20 x 22 x 51in. inside 34 x 34 x 79in. overall Digital controls, 120v, 1ph, RS-232 3 adjustable shelves, needs work, selling as-is (1) available

24 cu. ft. Lab Freezer Fisher Scientific model 425F

Stock Number: G-3036 24 cu. ft. Lab Freezer Fisher Scientific model 425F Mfg. Fisher Scientific Model 425F Freezer, rated to -30 deg. C 29 x 26 x 60in. inside 36 x 32 x 89in. overall 115v, 1hp., R22 (4) adjustable shelves Gets cold but does not appear to have a temperature adjustment. (1) available
